Storage DE4800H 128G HICless Hybrid Flash 2U12 LFF

DE4800H 128G HICless Hybrid Flash 2U12 LFF Form factor: ,2U rack mount RAID levels: ,RAID 0, 1, 3, 5, 6, and 10, Dynamic Disk Pools. (RAID 3 can be configured only through the CLI.) Controller system memory: ,128 GB per system (64 GB per controller), Cache mirroring between the controllers. Flash-backed cache protection (includes ,battery for destaging to flash) Expansion enclosure support: ,7x DE120S, 7x DE240S or 4x DE600S Drives bays: ,12 LFF drive bays in the the main (base) unit enclosure Drives: ,7.2K rpm SAS HDDs7.2K rpm SAS FIPS HDDs Host connectivity: , Base ports (per controller enclosure with two controllers): *4x 10/25 Gb iSCSI (DAC or SW fiber optics, LC) , Host connectivity ports provided using host interface cards (HICs). Listed below are the ports per enclosure. Each enclosure supports two controllers: *8x 12 Gb SAS host ports (Mini-SAS HD, SFF-8644) (4 ports per controller) *8x 10 ,Gb BaseT ,host ports (RJ45 Cat5/6 copper cables) ,(4 ports per controller) *8x ,16/32 Gb FC SFP+ host ports (SW fiber optics, LC) (4 ports per controller) Power supply: ,Two redundant hot-swap 913 W (100 - 240 V) (2U24 enclosures) or 2325 W (200 - 240 V) (4U60 enclosures) Platinum AC power supplies. Standard software ,features: ,Dynamic Disk Pools, SSD read cache, snapshots (up to 512 snapshots max), volume copy, thin provisioning (DDP only), encryption (requires optional FIPS drives), and data assurance. Dimensions (HxWxD mm): ,85x447x483 Weight: ,25.07 kg Záruka: , ,3 years Odkaz na stránku výrobcu: ,https://lenovopress.lenovo.com/lp2072-lenovo-thinksystem-de4800h-and-de4800f-storage-arrays
